Glycol Chiller

Lub glycol chiller system siv qee qhov concentration ntawm glycol kua txias raws li cov tub yees, thiab cov ntsia hlau hom siv lub plhaub ua haujlwm siab thiab lub raj cua kub exchanger ua cov evaporator. Qhov siab tshaj plaws ib chav tsev muaj peev xwm ncav cuag 1130kW. Lub semi-hermetic ntsia hlau compressor muaj qhov ua tau zoo tshaj plaws nyob rau hauv nruab nrab qhov kub thiab txias. Lub zog txuag hluav taws xob zoo sib piv tuaj yeem txuag hluav taws xob thiab cov nqi khiav lag luam rau cov neeg siv.

Lub peev xwm txias: 52.8kW ——1064.2kW / 15.1RT — 304RT
Cov tub yees: R22, R404A, R507A (yeem)
Fais fab mov: 3P-380V-50Hz (Customizable)
Compressor: Semi-enclosed ntsia hlau compressor (ib zaug / ob)
Chilled Dej Flow: 11m³ / h - 224m³ / h (Inlet / qhov hluav taws xob 12 degree / 7 degree)
Dej txias: 12.4m³ / h - 249.2m³ / h
Qhov kub thiab txias: -35 degree -2 degree
Hom Lub Npe: Feizhong

Xa kev nug

Khoom Taw Qhia Technical Parameter

vim li cas thiaj xaiv peb Glycol Chiller

Glycol Chiller kuj hu ua Brine chiller, nws siv qee qhov concentration ntawm cov dej ntsev tov raws li cov tub yees, thiab siv tshwj xeeb los tiv thaiv corrosion high-efficiency leeg raws li cov cua kub pauv ntawm cov evaporator qhuav. Nws txais kev tsim qauv tsis muaj teeb meem thiab muaj ib lossis ntau dua compressors uas muaj ntau yam tsis muaj kev ywj pheej. Lub glycol tub yees system, uas yog, cov condenser thiab evaporator dej sib koom, thiab cov tub yees tshuab tsis cuam tshuam rau ib leeg. Cov neeg siv tuaj yeem tswj tau tus lej pib ntawm compressors los ntawm qhov kub thiab txias raws li qhov loj ntawm lub load, kom lub zog ua haujlwm ntawm chav tsev txo thiab txuag lub zog. Thaum ib qho ntawm cov compressors yuav tsum tau kho, lwm cov compressors tuaj yeem ua haujlwm ib txwm, thiab kev nyab xeeb thiab kev ntseeg siab ntawm ethylene glycol chiller ua haujlwm tau zoo heev. Cryogenic chiller tuaj yeem muab cov tub yees brine ntawm -35 degree --2 degree, thiab tuaj yeem siv dav hauv cov txheej txheem hauv kev lag luam tshuaj, tshuaj, metallurgical, dej haus thiab zaub mov.

Khoom nta

Ntsia Hlau Compressors

Glycol rau cov cua txias siv thoob ntiaj teb nto moo hom semi-hermetic ntxaib-ntsia hlau compressor.
High efficiency 5: 6 patented asymmetric rotor hniav profile.
Plaub-theem lossis stepless muaj peev xwm tswj qhov system.
High-precision SKF, FAG xoom-clearance bearings.
Glycol cooler built-in roj lim siv ob txheej txheej pom, uas muaj cov roj pom zoo thiab cov evaporator tuaj yeem siv nws lub peev xwm siab tshaj plaws.
Glycol dej chiller lub cev muaj zog yog ua los ntawm high-efficiency silicon steel thiab tsim tshwj xeeb zawj. Nws yog nruab nrog sab hauv thiab sab nraud omnidirectional cua txias ntws raws thiab qhov tsawg kawg nkaus kev poob siab tsim ntawm qhov nkag thiab qhov hluav taws xob, ua rau lub compressor zoo heev.
Glycol system Built-in sib txawv siab roj muab lubrication system txo qhov hnav.
Axial tsis tu ncua cua kis tau tus mob thiab patented tso pa chamber tsim txo kev co thiab suab nrov.

Thaum tshav kub kub Exchanger

Cryo chillers 'lub plhaub-thiab-tube high-efficiency tshav kub exchanger yog optimized thiab tsim los ntawm lub computer kom optimize tsis thiab xyuas kom meej qhov zoo tshaj plaws tshav kub exchanger efficiency.
Advanced high-efficiency tshav kub hloov raj zoo heev ua rau lub tshav kub hloov coefficient, txo qhov loj ntawm lub tshav kub exchanger, thiab txuag chaw installation.

Hluav taws xob tswj

Thoob ntiaj teb renowned brand electronic control Cheebtsam thiab industrial qib programmable controllers.
Lub vijtsam loj LCD qhia txog ntau yam kev ua haujlwm ntawm cov khoom siv tswj.
Kev tiv thaiv hluav taws xob siab thiab tsis tshua muaj hluav taws xob, kev tiv thaiv roj qib, kev siv hluav taws xob overheating, lub cev muaj zog overheating, kev tiv thaiv overcurrent, theem poob, rov qab theem tiv thaiv, tiv thaiv dej txiav, tiv thaiv kev tiv thaiv, thiab lwm yam.
Cov kev tiv thaiv tsis siv neeg ua haujlwm tiav, ua kom muaj kev ntseeg siab ntawm cov khoom lag luam.
Rau ntau lub tshuab compressors, nws tuaj yeem hloov pauv kom ua tiav qhov sib npaug ntawm lub sijhawm khiav ntawm txhua lub tshuab compressor hauv lub sijhawm ua haujlwm, thiab ua tiav txhua lub tshuab compressor hnav.
Muaj glycol chiller muaj kev tswj hwm kev ua haujlwm xws li kev ua txhaum cai thiab kev kaw haujlwm, qhov ntsuas kub tam sim no, qhov ntsuas kub ntawm keeb kwm thiab kev kaw cia, pib pib thiab nres. Nyob rau tib lub sijhawm, nws tuaj yeem muab cov qauv kev sib txuas lus nrog cov chaw taws teeb tswj kev ua haujlwm raws li cov neeg siv khoom xav tau, kom ntseeg tau tias qib siab ntawm automation hauv cov khoom lag luam.

Expansion Valve

Glycol chav tsev txias txais yuav cov npe nrov thoob ntiaj teb ntawm kev tswj xyuas thermal induction expansion li qub thiab hluav taws xob nthuav tawm li qub ua rau lub tsev kom ua tiav kev ua haujlwm zoo thiab txhim kho kev lag luam txawm tias tag nrho cov khoom thauj lossis ib feem.

Txhim khu kev ntseeg thiab ua tiav kev xeem

Tom qab kev sib dhos ua tiav, nws dhau los ua qhov ntsuas huab cua nruj kom pom qhov ntsuas.
Kev ntsuas siab tuav ntev li 12 teev.
Tag nrho cov load ua haujlwm kuaj ua ntej tawm hauv lub hoobkas.

Yooj yim rau kev thauj mus los, kev teeb tsa thiab kev debugging

Tag nrho cov khoom tau ntim nrog cov tub yees ua ntej tawm hauv lub hoobkas. Tom qab cov cuab yeej raug teeb tsa, txuas lub qhov dej thiab lub hwj chim qaum, thiab nias lub pob "hwj chim rau" kom paub txog kev ua haujlwm ntawm cov khoom.

Siab zoo

Kev ua haujlwm ruaj khov

cov cuab yeej siv siab heev

Kev tiv thaiv ib puag ncig

pab neeg tshaj lij

Kev nyab xeeb & txuag hluav taws xob

ib-stop daws

High Energy Efficiency Ratio

Daim ntawv thov Glycol chiller

Kev lag luam tshuaj

Glycol chillers kuj tau siv dav hauv kev lag luam tshuaj. Piv txwv li, hauv kev tsim cov nitric acid, sulfuric acid thiab lwm yam tshuaj, cov txheej txheem kev npaj yuav tsum tau txias kom ntseeg tau tias cov tshuaj tiv thaiv kab mob ua haujlwm zoo. Lub sijhawm no, glycol chiller tseem tuaj yeem ua si tawm nws lub tub yees zoo dua.

Kev lag luam metallurgical

Glycol chiller yog cov khoom siv tub yees siv tau zoo heev hauv kev lag luam metallurgical. Nws siv ethylene glycol ua lub tub yees thiab siv nws qhov qis qis thiab ruaj khov lub cev thiab tshuaj lom neeg kom ua tiav cov nyhuv txias. Hauv kev lag luam metallurgical, glycol chiller tau siv dav hauv ntau qhov chaw xws li lub tshuab cua txias, tshuab cua txias, lubricating roj txias, compressed cua txias, thiab lwm yam. Nws yog ib qho tseem ceeb ntawm cov khoom siv hlau.

Kev lag luam kws tshuaj

Glycol chillers muaj cov ntawv thov tseem ceeb hauv kev lag luam kws tshuaj. Hauv cov txheej txheem tshuaj, ntau yam tshuaj yuav tsum tau ua kom txias, uas glycol chiller tuaj yeem txo qhov kub thiab txias mus rau qhov xav tau ntau yam, kom ntseeg tau tias cov tshuaj zoo thiab ruaj khov.

Kev Lag Luam Dej Haus & Khoom Noj

Glycol chiller kuj tseem tsim nyog rau kev lag luam dej haus thiab zaub mov. Thaum lub sij hawm ua ntau hom dej haus thiab zaub mov, nws yog ib qho tsim nyog yuav tsum tau txias thiab khaws cov zaub mov los yog tso rau hauv lub tub yees rau cov khoom ntim, thiab tib lub sijhawm, nws tseem yuav tsum tau ua kom tau raws li qhov kub thiab txias. Glycol chillers muab ib qho yooj yim heev, ceev thiab raug cua txias.

Dab tsi yog glycol npias system?

Kev tsim cov khoom siv tes ua brewery yog txheej txheem biochemical zoo heev. Cov malted barley yog crushed thiab pub rau hauv ib lub mash tun, ces mus rau hauv lauter tun qhov twg dej yog ntxiv ntawm qhov kub thiab txias. Qhov sib tov ntawm crushed malt thiab dej yog hu ua mash. Thaum ua tiav, cov mash yog lautered thiab tom qab ntawd xa mus rau lub sterilized brew kettle, nyob rau hauv uas lub wort yog ces boiled, concentrated thiab hops yog ntxiv rau tsw thiab aroma. Yog li txoj hauv kev zoo los tswj qhov kub thiab txias thaum lub sijhawm ua haujlwm yog siv brewery chillers.

Tom qab cov txheej txheem boiling, hops thiab protein sediments raug tshem tawm nyob rau hauv lub whirlpool txheej txheem. Lub wort yog ces txias mus rau ib tug kub rau fermentation, feem ntau yog thawj zaug txias los ntawm phaj kub exchanger thiab thib ob txias los ntawm chilled dej muab los ntawm glycol brewery chillers.

Hauv glycol txias system, npias hla cov hlab mus rau lub phaj chiller thiab ua txias. Cov txheej txheem chilling ua haujlwm los ntawm kev quab yuam cov kua txias (glycol) raws cov hlab rau lub phaj chiller, uas feem ntau yog cam khwb cia txhuas, thiab tom qab ntawd los ntawm cov kais dej, yog li ua kom lub npias txias.

Peb glycol chiller tshuab feem ntau yog siv rau wort txias, tswj kub thaum lub sij hawm fermentation, txias hlab / tun, pre-packaging txias thiab cia txias, nrog rau lwm yam kev siv nyob rau hauv fermented khoom siv tes ua dej haus.

Kev tsim qauv tsim & cua txias muaj peev xwm ua tau raws li koj cov kev xav tau cua txias. Tiv tauj peb hnub no!

abc

Txais tos nug!

Thov muab cov ntaub ntawv parameter thiab peb yuav muab cov lus hais meej thiab tsim nyog rau koj hauv 24 teev:

1: Fais fab mov (voltage, theem, zaus)

2: Lub tub yees muaj peev xwm

3: Cov tub yees

4: Chilled dej qhov hluav taws xob kub, dej ntws tus nqi

5: Tus neeg siv lub davhlau ya nyob twg txias qhov sib txawv

6: Txoj kev ua kom txias: cua txias lossis dej txias

FAQ Txog Glycol Chiller

Q:1.Vim li cas thiaj siv glycol chillers?

A: Glycol muaj peev xwm nqus thiab tso tawm cov cua kub ntau yam tsis hloov nws qhov kub thiab txias. Qhov no ua rau nws zoo tagnrho rau siv nyob rau hauv daim ntawv thov tub yees xws li haus dej txias. Glycol yog ib qho tseem ceeb ntawm cov dej hloov hluav taws xob hauv kev siv chiller.

Q:2.Puas yog glycol pab ua kom txias?

A: Qhov ntsuas kub qis uas tuaj yeem ua tiav los ntawm kev siv glycol kuj tau txais txiaj ntsig zoo rau lub tshuab ua kom txias, uas tuaj yeem nyob twj ywm txias ntawm qhov kub qis dua li dej ib leeg. Qhov no yog vim li cas glycol txias tshuab tau dhau los ua ntau dua li qhov qub.

Q:3.Puas yog glycol chillers muaj kev nyab xeeb?

A: Txawm hais tias lub cev lub cev ntawm propylene glycol zoo ib yam li cov ethylene glycol, polypropylene glycol tsis muaj tshuaj lom thiab yog li muaj kev nyab xeeb rau siv hauv cov khoom noj chillers.

Q:4.Dab tsi yog pH ntawm glycols?

A: Cov pH ntawm feem ntau inhibited glycols yog nyob rau hauv thaj tsam ntawm 9.0 txog 10.5. Thaum diluted rau 30% rau 50% tov, pH poob rau ntawm 8.3 thiab 9.0. pH nyeem hauv qab 8.0 qhia tias feem ntau ntawm inhibitor tau depleted thiab ntau inhibitor yuav tsum tau ntxiv.

Q:5.Cov kab mob puas tuaj yeem loj hlob hauv glycol?

Q:6.Kuv yuav ua li cas tuav kuv lub glycol chiller?

A: Tshawb xyuas cov cim qhia ntawm icing, lub cev puas tsuaj rau lub insulator, los yog glycol leaks. Glycol Mixture - Txheeb xyuas qhov viscosity thiab qhov xwm txheej ntawm glycol-dej sib tov txhua rau lub hlis. Txhua kaum yim lub hlis, sim qhov chaw khov ntawm qhov sib tov siv lub refractometer. Kho lossis hloov qhov sib tov raws li xav tau.

Xa lus nug

Peb muaj ib pab neeg ua haujlwm siab tshaj plaws thiab cov kws tshaj lij tom qab muag uas tuaj yeem muab 24- teev cov kev pab cuam sab laj online.

Peb sov siab txais tos koj rau cov lag luam wholesale customized chiller ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas.

Pls tiv tauj peb kom paub meej ntxiv.

Cim npe nrov: Tuam Tshoj glycol chiller manufacturers, lwm tus neeg, Hoobkas

Model LSB			55Z.1	75Z.1	95Z.1	105Z.1	130Z.1	140Z.1	165Z.1	175Z.1	190Z.1	210Z.1	230Z.1	270Z.1	285Z.1	315Z.1	340Z.1	350Z.1	415Z.1	450Z.1	480Z.1	530Z.1	540Z.2	570Z.2	630Z.2	680Z.2	700Z.2	830Z.2	900Z.2	960Z.2	1060Z.2
Nominal Cooling Peev Xwm		kW	52.8	72	94.5	102.9	127.4	137.7	162.2	173.2	187.5	209	227.5	271.1	283.9	314.5	341.2	352.2	413.7	447.6	481.2	532.1	542.2	567.8	629	682.4	704.4	827.4	895.2	962.4	1064.2
		Kcal/h × 104	4.5	6.2	8.1	8.9	11	11.8	13.9	14,9	16.1	18	19.6	23.3	24.5	27	29.3	30.3	35.6	38.5	41.4	45.8	46.6	49	54	58.6	60.6	71.2	77	82.8	91.6
		RT	15.1	20.6	27	29.4	36.4	39.3	46.3	49.5	53.6	60	65	77.5	81	90	97.5	100.6	118.2	128	137.5	152	155	162	180	195	201.2	236.4	256	275	304
Hwj chim			3N / 380V / 50Hz
Nominal Working Condition Input Power		kW	20.1	29.5	36.8	40.4	49.2	53.6	60.1	63.2	69.6	76	84.6	98	103.5	112.2	120.7	124.6	143.6	159.2	169.1	190.2	196	207	224.4	241.4	249.2	287.2	318.4	338.2	380.4
Compressor	Hom		Semi Enclosed Ntsia Hlau Compressor
	Pib hom		25% Load + Y-△ ncaj qha pib
	Tswj zog		Min txias peev xwm -50%-75%-100% lossis 10%-100% steplessly adjustable
	QTY		1	1	1	1	1	1	1	1	1	1	1	1	1	1	1	1	1	1	1	1	2	2	2	2	2	2	2	2	2
Condenser	Hom		Plhaub Tube Condenser
	Dej ntws	t/h	12.4	16.9	22.1	24.1	29.4	32.3	38	40.2	44	47.6	52.4	63	65.8	72	78	81	94	103.6	110.6	124.6	126	131.6	144	156	162	188	207.2	221.2	249.2
	Pipe Dia	mm	2-DN65	2-DN65	2-DN65	2-DN80	2-DN80	2-DN80	2-DN100	2-DN100	2-DN100	2-DN100	2-DN125	2-DN100	2-DN125	2-DN125	2-DN125	2-DN125	2-DN150	2-DN150	2-DN150	2-DN150	4-DN100	4-DN100	4-DN125	4-DN125	4-DN150	4-DN150	4-DN150	4-DN150	4-DN150
	Dej Siab poob	kPa ua	40-70
Evaporator	Hom		Qhuav Plhaub Thiab Tube Thaum tshav kub kub Exchanger
	Dej ntws	t/h	11	15.2	19.6	22	26.9	29.5	34.8	36.7	40.2	43.5	47.9	57	60.2	65.9	71.3	74	86	94.6	101	112	114	120.4	131.6	144	156	162	188	202	224
	Pipe Dia	DN	2-DN65	2-DN65	2-DN65	2-DN80	2-DN80	2-DN100	2-DN100	2-DN100	2-DN100	2-DN100	2-DN125	2-DN125	2-DN150	2-DN150	2-DN150	2-DN150	2-DN150	2-DN150	2-DN150	2-DN150	2-DN200	2-DN200	2-DN200	2-DN200	2-DN200	2-DN200	2-DN200	2-DN200	2-DN250
	Dej Siab poob	kPa ua	50-90
	Temp Control		Chilled Water Temperature Control
Cov tub yees	Lub npe		R22/R404A/R507A
	Tswj txoj kev		Thermal Expansion Valve
	Charge Volume	kg	16	20	26	28.5	32	36	41	45	55	58	60	73	78	86	95	101	116	130	142	150	146	156	172	190	202	232	260	284	300
Lubricating Roj	Qauv		Mineral Roj / Ester Roj
Loj	L	mm	2000	2200	2750	2750	2900	2900	3000	3000	3000	3300	3300	3300	3300	3400	3400	3400	3600	3600	3600	3900	4500	4500	4250	4250	4750	4750	4750	4750	5200
	W	mm	700	700	800	800	900	900	1000	1000	1000	1000	1000	1100	1100	1100	1200	1200	1200	1200	1200	1300	1600	1600	1600	1600	1700	1700	1700	1700	2000
	H	mm	1450	1450	1500	1500	1650	1650	1750	1750	1750	1850	1850	1850	1850	2000	2000	2000	2200	2250	2300	2300	2200	2200	2300	2300	2300	2400	2400	2400	2600
Suab nrov		dB (A)	69	69	69	70	70	70	70	70	70	70	70	69	69	69	70	70	70	70	71	71	71	71	71	72	72	73	73	75	75
Qhov hnyav		kg	800	950	1100	1200	1350	1500	1650	2700	1900	2100	2300	2600	2750	2920	2200	3300	3600	3900	4100	4250	4300	4500	5200	5450	5900	6300	7500	8100	9700
Tus phooj ywg ceeb toom: 1. Qhov kev ua haujlwm nominal ntawm lub peev xwm txias yog tias lub condenser inlet dej kub yog 30 degree, lub qhov hluav taws xob dej kub yog 35 degree, lub evaporator inlet dej kub yog -5 degree, thiab qhov hluav taws xob dej kub yog {{ 4}} degree. 2. Tus qauv khoom lub tub yees yog ethylene glycol aqueous tov. Thaum siv cov tshuaj brine raws li cov tub yees, cov evaporator yuav tsum muaj corrosion-resistant, thiab cov dej txias ntws yuav tsum yog × 1.2 npaug. 3. Qhov loj ntawm cov brine yog: ethylene glycol aqueous tov 40%, CaCl aqueous tov 20.9%; 4. Qhov ntsuas lub suab nrov yog 3. 5. Ntxiv nrog rau cov lus qhia saum toj no, lub tuam txhab tuaj yeem muab cov khoom tsis zoo raws li qhov kev ua tau zoo ntawm cov neeg siv khoom.
